cement system that allows creating a reliable barrier for cementing steam injection wells where the working agent's temperature exceeds 300°C. The unique composition withstands cyclical temperature loads, preventing cracking and, as a result, ensuring the integrity of the annular space.
SJC (STEAM JET CEM) REPRESENTS A MULTICOMPONENT MIXTURE OF MATERIALS, PRIMARILY OF INORGANIC ORIGIN.
Appearance: powder, ranging from gray to dark gray color Solubility in water: partial
Properties of cement stone
Density of cement slurry — 1.85 g/cm³ – 2.0 g/cm³ Compressive strength after five cycles: at 25°C — not less than 15 MPa at 195°C — not less than 20 MPa Setting time — adjustable.
The stone withstands temperature variations in radial and axial directions;
absence of cracks in the cement stone, resulting in no heat loss during steam injection into the formation;
increased trouble-free operating period of the well.
Operating temperature range from 205°C to 100°C Cyclic temperature range: from 110°C to 250°C
Packaging and storage conditions
PNS (Cement Systems for Steam Injection Wells) is packaged in soft containers (FIBC) weighing up to 1 ton, equipped with triple polyethylene liners. The product is recommended to be stored in a dry place on pallets away from moisture, open flames, and heating devices. After opening the FIBC, it is necessary to ensure the packaging is airtight to prevent product spoilage. The product has a shelf life of at least 12 months.
Suitable for cementing technical and operational columns in intervals of viscous hydrocarbons where steam injection is applied.
The cement system withstands multiple temperature fluctuations (heating and cooling cycles). It withstands loads due to its elastic properties.
It has increased sedimentation stability and reduced water loss, which has a positive effect on the results of cementing the interval.
График набора прочности
